Top Quality Yg8 Carbide Rods Blanks

Basic Info.

Model NO.	YG8 carbide rods
Grades	K10/K20/K30/K40/Yl10.2/Yg6/Yg6X/Yg8/Yg10X/Yl10.2
Main Using Purpose	Carbide Body for Drill Bits/ Endmills / Reamers
Surface Finishing	Polished and Unpolished
Cobalt Percentage	From 3% to 30% Based on Different Grades
Grain Sizes Selection	Ultra Fine, Fine, Medium, Coarse
Wc+Co Powder	100% Virgin Material
Transport Package	Standard Packing for Export
Specification	WC+Co Powder
Trademark	Laser mark available
Origin	Zhuzhou City, Hunan, China

Product Description

Application of our YG8 tungsten carbide rods blanks:
Main used for making varioius drill bits, automobile special cutter, printed circuit board, special cutters, engine special cutters, horologe, processing special cutters, integral vertical milling cutter, graver and etc. Besides, they can be used for making of cemented carbide stamping head,core bar & perforation tools. *We have stock of the carbide rods in regular sizes, which means we can send the goods to you from China at the same day of order confirmed.

Dimensions of yg8 carbide rods: Diamter from 1.0mm to 30mm , lenght between 10-400 mm(standard length is 330 mm).

We provide a wide range of cemented carbide rods in different dimensions, like solid carbide rods, rod with single straight hole, double holes and also twisted holes.
Recommend grade list of yg8 tungsten carbide rods:

ISO Grade	Co%	Density(g/cm3)	Hardness		Bending Strength(N/mm2)	Grain Size(μm)
			HV30 (kg/mm2)	HRA (ISO3738)
K05-K10	6	14.8	1860	93.5	3800	<0.5
K05-K10	6	14.9	1510	91.4	3000	1.0
k20-K30	8	14.6	1700	92.7	3800	0.8
K30	8	14.8	1300	89.6	2500	1.2
K20-K30	10	14.5	1600	92.1	3800	0.7
K20-K30	12	14.1	1680	92.6	3800	<0.5
K40	15	14	1330	90	3800	0.8
K40	20	13.5	-	85	2900	1.2

Main types of the tungsten carbide rods:

We also can produce the customized carbide rods, not only the sizes & shape, but also the grades based on your using purpose. If you need more specification of the tungsten carbie rod, please kindly contact us.
Tolerance Standard For Grinding:
We also can do specified tolerance based on your requirement.

Quality Control System: We always follow the high quality standard for production, from the material preparing to final product ready, all product will go through 3 inspections before we send them to you. Our professional teams will take care of your product and ensure the good and stable quality for all batches.Our regular product is tungsten carbide tips, carbide inserts, end mills,carbide saw tips,carbide mining parts, carbide rods, plates and stripes.We also have rich experience for customized product, we make your designs become real product, which perfectly match your need. We have many successful projects on the for our clients in different countries.

Packing:A. Standard packing 1).Plastic boxes with foam inside and carton outside. 2).Paper boxes with foam inside and carton outside. 3).Inner boxes/packing material inside and plywood box outside (for heavy product). B. Customized packing available: We can do special packing based on client's requirements..
